History¶
Design decisions is about why LeakCanary works the way it does. This page is about how it got that way: what it was before it was a library, and what has been thrown out since.
LeakCanary was written by Pierre-Yves Ricau, who has maintained it ever since 2015. A lot of what it is today came from other people though, and where a part of LeakCanary exists because someone else built it or argued for it, this page tries to say so.
It started with wanting to know when to look¶
Before there was a library there was a habit. Dump the heap at a random moment, pull the file off the device, open it in Eclipse MAT, and go looking for something that had accumulated. Most of those dumps showed nothing, and the ones that showed something did so long after the change that caused it.
What was missing wasn’t a way to analyze a heap dump. It was a way to know that taking one was worth the trouble β a trigger. That is the idea LeakCanary was built on, and everything it is now known for, including analyzing the heap dump on the device, came afterwards.
The memory diaper¶
The first version was not a library and was not called LeakCanary. It was a 154 line debug-only class
called ActivityMemoryDiaper, written in March 2015 inside Square’s point of sale app for Android.
Its notification icon was a nappy with a safety pin:
It watched every destroyed activity through a weak reference, waited five seconds, forced a garbage
collection, and if the activity was still there, dumped the heap and posted a notification that
opened an email with the .hprof file attached, under a message that read:
You just found a memory leak and the Register Android team loves you for that. Please email seller-android@ so that we can fix it.
Three ways to notice the same thing¶
The detection technique changed twice within the first fortnight, and the third attempt is what LeakCanary still does today.
It started with a weak reference to the activity itself. That was replaced nine days later out of a worry about the tool changing what it was measuring:
Detect memory leaks with no weak references
We’re now attaching an object to the activity and checking if it was finalized. This avoids holding a weak ref to the activity, which may expand its lifetime and can also be confusing when analyzing heap dumps.
A week after that, finalization was replaced by weak reachability, for the reason the current design still rests on:
Detect weakly reachable leak tags
In theory, as soon as a LeakTag becomes weakly reachable it will be enqueued to the reference queue. This will happen earlier than the finalize() method being called, so we’ll hopefully be able to have less false positives due to weak references to activity instances.
Watching for weak reachability rather than for collection is still how it works.
Becoming a library¶
The name didn’t make the trip. It was settled on Slack, in three messages:
P-Y
Is “memory-diaper” a suitable project / repo name? I’m in lack of a better pun.
Logan Johnson
No, it’s gross and not really funny. I wouldn’t want to see it on a slide deck.
Eric Denman
maybe something “canary in the coal mine” related?
On 5 April 2015 the detection code was lifted out of the app into a repository of its own, under a commit called “Introducing LeakCanary, au revoir memory leaks”, and started using a headless version of Eclipse MemoryAnalyzer. Analysis moved onto the device, and the code that took a heap dump could now tell you what was in it.
The month that followed β 5 April to 30 April 2015, 50 commits β is where most of the design that survives today was settled.
The first LeakCanary logo was a sprite lifted from Swipey Bird, a Flappy Bird clone built at a Square hack week in 2014, in which you made the bird fly by swiping a credit card through a card reader.
A day later it was replaced by an icon of LeakCanary’s own, assembled rather than drawn: a photograph of a real canary, outlined in Photoshop, over a shield generated by Roman Nurik’s free Android Asset Studio.
The outline was rough, so Romain Guy redrew the whole thing in a vector file β his version on the right:
Two things from that month are worth pulling out.
It was made to work out of the box. In April 2015 LeakCanary was a set of parts you wired
together in your Application class: construct a heap dump listener, hand it to a watcher, hold on
to the watcher β plus a sample app demonstrating that wiring, and a sample activity carrying the code
that displayed the leaks. Jesse Wilson suggested that instead LeakCanary should have a user interface
and should work out of the box with no configuration: all of that code belonged in the library.
Within days it was there, and the wiring had collapsed to a single LeakCanary.install(this). It
disappeared altogether in version 2, which
installs itself. KeyedWeakReference, a class
LeakCanary still has, first appears that same month.
Analysis moved to a separate process, because the app it was built for ran out of memory parsing
its own heap dumps. That decision stood for four years and cost every app that used LeakCanary a
guard in its Application class, until Shark made in-process analysis cheap enough to be the default
again.
Released¶
LeakCanary was open sourced on 7 May 2015, as a single squashed commit. The first public release, the next day, was 1.3. Not 1.0: versions 1.0 through 1.2.9 had already been used internally by the app it came from, and the numbering simply carried on.
Four heap parsers¶
The most rewritten part of LeakCanary is the thing that reads the heap dump. It has been replaced three times, each time for the same reason β the previous one cost too much memory to run on a phone.
AndroMAT. The first version vendored Eclipse MAT’s parser directly into the library. Not a fresh fork: an existing Android port by Joe Bowbeer. Bitbucket dropped Mercurial hosting in 2020 and took AndroMAT with it; the last working copy of that page is a 2016 snapshot.
HAHA. Ten days later the parser moved out into a repository of its own, HAHA, which put the MAT-derived code behind a dependency instead of inside the library.
perflib. In July 2015, HAHA 2.0.2 swapped MAT’s parser for perflib, the heap dump parser from Android Studio. The changelog entry is four words long about why: “This fixes crashes and improves speed a lot.”
Shark. perflib was still built for a workstation. LeakCanary 2 replaced it with a parser written from scratch for a small memory footprint, which is what made analysis in the app’s own process practical: a 160 MB heap dump that takes 2 GB of memory to open in Android Studio opens in 40 MB with Shark. That number is why the separate process stopped being the default, and it is the argument the design page makes.
LeakCanary 2¶
Released 27 November 2019, after 7 months, 3 alphas and 5 betas, 23 contributors and 493 commits. About 6000 lines of Java became about 16000 lines of Kotlin, most of the increase being Shark and a much larger test suite.
It started from a list of complaints rather than a list of features, written down before any code was touched. Some of that list was about the analysis, but the entries that changed how LeakCanary behaves were about living with it:
LeakCanary 2
LeakCanary only processes one leak at a time, so if there are several leaks the phone will just alternate between dumping (freezing) and analyzing which is frustrating.
Most people have no idea how much they can configure LeakCanary.
LeakCanary is very customizable but that requires copying some library code and doing things the right way. The API provides ways to replace specific components but is not driven by use cases (e.g. “I want to sometimes disable leakcanary” vs “I want to replace the heap dumper”)
Those are notes from a conversation with Ty Smith about running LeakCanary across Uber’s app, and they are why the reporting became batched and why the configuration API was rebuilt around what people were trying to do rather than around which component they wanted to replace.
Three changes to how leaks are reported came out of that rewrite:
- The leak trace was redesigned. The current layout β root at the top, one reference per line, object state annotated alongside β was not the first idea. The design notes argued for putting the garbage collection roots at the bottom, by analogy with a stack trace, and half a dozen prototypes were drawn that way over a single day in October 2018 before the direction was kept as it was.
- Every field stopped being printed. Version 1 could expand a trace to show every field of every object in it. That was replaced by labels: short strings an object inspector attaches because they say something worth saying.
- Reporting became batched. Version 1 triggered on every retained instance. Version 2 waits for the app to go to the background, or for five retained instances in the foreground, then finds all the leaks at once and groups the identical ones.
The rewrite began in a Square hack week, the first week of April 2019, and the Kotlin was mostly other people’s: over its first four days Colin Marsch and Brandon Cheng translated the 1.x code class by class in a series of small pull requests. Artem Chubaryan later added Android TV support, and a run of memory and speed improvements to Shark.
The release date was a conference. Version 2.0 alpha 1 was tagged at 06:43 Paris time on 23 April 2019, in the middle of Android Makers, where the talk was LeakCanary 2: Leaner, Better, Faster, Kotliner!. The week before it was the busiest week of the entire rewrite, at 67 commits, and two days before the tag came a pull request titled “Fixes based on using v2 with Android Makers” β the app it was being tested against was the conference’s own.
There is a separate upgrade guide for the API changes.
Reading an obfuscated heap dump¶
A heap dump from a release build names classes a.b.c, which makes a leak trace useless. Being able
to read one arrived in three pieces over ten months of 2019 and 2020, all of them MichaΕ ZieliΕski’s:
Shark learned to parse a ProGuard mapping file and apply it while building a leak trace, a Gradle
plugin put that mapping file into the APK as an asset so that it would be on the device when it was
needed, and the same deobfuscation became an option on the shark command line for a heap dump you
already have.
Expanders, and where they came from¶
The idea that a leak trace should show a collection the way you would write it, rather than the way it is implemented, is not LeakCanary’s. It came from the leak checking harness the Android Studio team runs against Android Studio itself, built there by Nathan Paige as a set of expanders.
That harness is named BLeak and finds leaks the way the BLeak paper does β John Vilk and Emery D. Berger, PLDI 2018 β but the paper is about JavaScript in web applications, and the expanders are the Android Studio implementation’s own. LeakCanary shipped its version of expanders in 2.8, and then reused the same machinery two years later when implementing BLeak / heap growth detection, which is the one part of LeakCanary that finds leaks without anything being watched.
